Lacquer Curing Oven for aluminum soft tubes

Product Description

GHD curing oven, also called aluminum tube inner coating curing oven, is a supporting equipment in the aluminum tube production line, used for curing the aluminum tube inner wall after spraying. This machine is a necessary equipment for all internal wall spraying equipment in the aluminum tube production line. The machine is equipped with a separate drive motor, which can operate synchronously with the front and rear equipment or independently.

The sprayed embryo tube is driven by the conveying ship chain and transferred to the stainless steel "C" type ship in the curing furnace. Driven by the ship chain, it is circulated to the discharge port with the "C" type ship in the curing furnace. The model boat pours out the embryo tube after high-temperature baking and falls into the delivery pipe conveyor chain. The embryo tube is sintered in the curing oven for a certain period of time, and the inner spray liquid attached to the tube wall is baked and firmly fixed On the inner wall of the tube, thus completing the entire curing process.
